Specifications for FlameShieldä Silicone Tapes Part Numbers starting with "ABST" Triangular and Rectangular Profile MIL Spec Silicone Tape MIL-I-46852 Type I & II A-A-59163 Type I & II |
|||
| Property | Standard |
Test Result or Tolerance |
Test Method |
|
Thickness: ABST-TR-16 ABST-TB-16 ABST-RR-16 ABST-RB-16 ABST-RR-24 ABST-RB-24 |
.020" (20 mil) Centre .020" (20 mil) Centre .020" (20 mil) Uniform .020" (20 mil) Uniform .020" (20 mil) Uniform .020" (20 mil) Uniform |
+/- .002" | |
|
Width: ABST-XX-16 ABST-RR-24 |
1.00" 1.50" |
+/- .020" | |
| Length: ABST (all) | 36 feet | +/- 6.00" | |
| Color: ABST | Oxide Red, Black | N/A | |
|
Guideline Color (ABST-TR-16 only) |
Blue | N/A | |
| Operating Temperature |
-60ºC to +260ºC -76ºC to +500ºF |
||
|
Shipping Weight: ABST-T(X) ABST-R(X) ABST-24 |
155g / 5oz 190g / 6oz 480g / 17oz |
||
| Brittle Temperature | -65ºC / -85ºF | ||
| Interleave Material | .002" thick Mylar | ||
| Tensile Strength | 700 psi (minimum) | 1100 | ASTM D412 / D119 |
| Dielectric Strength | 400 V/mil (.001") | 575 |
MIL-I-46852 MIL A-A-59163 ASTM D-149 |
| Dielectric Constant | 2.94 @ 1KHz | ASTM D150 | |
| Resistance | 3 x 1014 ohms/cm3 | MIL-I-46852 | |
| Elongation | 300% (minimum) | 700 | ASTM D412 / D119 |
| Tear Strength | 85 psi (minimum) | 146 | ASTM D624 |
| Bond Strength (1" width) | 2 lbs (minimum) | 5.5 |
MIL-I-46852 ASTM D2148 |
| Adhesion |
Shall not unwind more than 1.0" after 3 minutes with 600g load |
0.12" | ASTM D2148 |
| Inclined Mandrel Tack Test (inch) | 0.25 | ASTM D2148 | |
| Water Absorption (by wt) | 3% (maximum) | 0.9% | MIL-I-46852 |
| Dissipation Factor | <0.0004 @ 1 KHz | ASTM D150 | |
|
Hardness, durometer Shore A |
55-65 | 55 |
ASTM D2148 ASTM D2240 |
Self-Fusing Mil Spec (Mil-I-46852 & A-A-59163) High-Temperature Silicone Tape
